MA80 Bifold Door
Experience the beautyand elegance of our Bifolddoors, available in a rangeof novel styles and diversecolors.
Quick Specs
MA80 Bifold Door Quick Specs
Fast product-selection information for early specification, enquiry and comparison.
Product Overview
Practical Aluminium Door System for Project-Based Supply
Fold, slide, open wide. Smartly designed panels stack neatly to one side, creating a generous opening that connects indoor and outdoor living. Compact when closed, expansive when open.
- Water Tightness : 350Pa
- Ultimate Pressure : Positive – 2000Pa
- Ultimate Pressure : Negative – 2000Pa
- 6mm+21Ar+6mm / 8mm+18Ar+8mm
Configurations
Product Configuration / Opening Diagrams
Configuration drawings illustrate the proposed opening arrangement, fixed and operable elements, and section details. Confirm dimensions, hardware, support conditions and installation interfaces in the approved project drawings.
System Data
System Parameters
Structural and system-level information is kept separate from glass, hardware and performance data so it is easier to review the product model.
| Series | MA80 |
|---|---|
| Product Category | MA80 Bifold Door system |
| System Type | Non- Thermal Break |
| Opening Method | Sliding |
| Frame / Sash Finish | Powder coated aluminium; standard and custom colours available |
| Project Customisation | Size, layout, glazing, hardware, colour and technical drawings should be confirmed from project drawings. |
Glass Data
Glass Specifications
Glass information is listed separately so build-ups and U-value references can be reviewed clearly.
| Available Glass Build-Up | 6mm+21Ar+6mm |
|---|---|
| Available Glass Build-Up | 8mm+18Ar+8mm |
Glass-table U-value and solar heat gain figures describe the listed glazing, not a verified whole-window or whole-door rating. Confirm whole-assembly performance for the specified frame, glass and opening configuration.
Customisation
Glass Configuration Options
These options can be selected according to project requirements and final specification.
Hardware
Hardware Options
Hardware options can be selected according to project requirements, operation preference, locking needs and the final door specification.
Standard Hardware Reference
- KSBG
Optional Hardware Upgrades
Colours
Standard Colour Options
Standard colour references are shown below. Custom powder coating can also be reviewed for project-specific requirements.
Performance
Maximum Performance
Performance data is separated from system structure and glass options for easier review.
| Water Tightness | 350Pa |
|---|---|
| Ultimate Pressure | Positive – 2000Pa |
| Ultimate Pressure | Negative – 2000Pa |
| Air Tightness [Sealed] | Positive – 75Pa – 57.39Ls⁻¹ Negative – 75Pa – 84.84Ls⁻¹ |
| Air Tightness [Unsealaed] | Positive – 75Pa – 70.79Ls⁻¹ Negative – 75Pa – 140.58Ls⁻¹ |
| Air Tightness [Net Leakage] | Positive – 75Pa – 13.40Ls⁻¹ Negative – 75Pa – 55.74Ls⁻¹ |
Note: Final product performance should be confirmed by project requirements, selected glass, configuration, site conditions and applicable Australian standards.
Applications
Where MA80 Bifold Door Is Used
Related Products
Related Products & Systems
FAQ
MA80 Bifold Door FAQ
How do bifold doors compare with sliding doors?
Bifold panels fold and stack to the side, while sliding panels travel along tracks past adjacent panels. For MA80 Bifold Door, review the configuration drawing, folding clearance and parked-panel position before comparing usable access. Overall frame width is not the same as the clear walk-through opening.
Is MA80 Bifold Door thermally broken?
MA80 Bifold Door is listed as a non-thermally broken aluminium system. Double glazing does not convert a non-thermally broken frame into a thermally broken system. Compare verified whole-door U-value and SHGC data for the proposed assembly; generic glass figures are not a whole-system rating. See YourHome glazing guidance.
What double-glazing options are listed for MA80 Bifold Door?
The published glass build-ups are 6mm+21Ar+6mm; 8mm+18Ar+8mm. These are the listed options for this model, not interchangeable approvals for every opening size. Confirm glass type, safety requirements, coating and configuration with the project schedule. Published glass-only thermal values must not be represented as whole-door performance.
Are bifold doors secure?
Security depends on the complete door assembly, its locking hardware, glazing and installation—not the operating style alone. For MA80 Bifold Door, include locking and access requirements in the inquiry and request the applicable hardware specification. No security rating is asserted without documentation for the selected configuration.
Does an AS2047 report cover every configuration?
No. Documentation must identify the relevant series, opening type, dimensions, glass, hardware and permitted variations. Compare the covered structural, water and air performance with the project requirements. The compliance documents should be checked for applicability to MA80 Bifold Door; a report for another model is not interchangeable.
What information is needed for a quote?
For MA80 Bifold Door, send drawings and schedules showing project location, opening sizes, quantities, glazing and performance requirements, finishes and expected delivery timing. Identify installation and delivery responsibilities. The quote is developed from the agreed supply scope; no fixed price or delivery lead time is assumed.
